Pinacho - Taurus 260 (D1024)
Home | Machines | Lathes | CNC lathes |
SPECIFICATIONS
| Brand | Pinacho |
| Machine no | D1024 |
| Type | Taurus 260 |
| CNC Brand | Fagor |
| Year of make | 1999 |
| Teach-in | |
| Distance between centers | 1.500 mm |
| Center height | 260 mm |
| Turning diameter above the bed | 520 mm ø |
| Turning diameter above the support | 320 mm ø |
| Passage | 80 mm ø |
| 3-jaw chuck | 310 mm ø |
| Spindle Speed | 0 - 2.000 RPM |
| Quick-change holder | |
| Machine size (lxwxh) | 4.000 x 2.000 x 1.900 mm |
| Machine weight | 3.100 kg |
